Name: Samtec RF047-A-92SP-M0SJ-0152
Brand: Samtec
SKU: 200-RF47A92SPM0SJ152
Price: 89.8 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-RF47A92SPM0SJ152

Mfr. No:

RF047-A-92SP-M0SJ-0152

Mfr.:

Samtec

Description:

RF Cable Assemblies 50 Ohm

Datasheet:

RF047-A-92SP-M0SJ-0152 Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec RF047-A-92SP-M0SJ-0152

Availability

Stock:: An unexpected error occurred. Please try again later.

3 Can Dispatch in 10 Days

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

$-.--

Ext. Price:

$-.--

Est. Tariff:

Pricing (USD)

Qty.	Unit Price	Ext. Price
	$89.80	$89.80
	$87.19	$871.90
	$84.65	$2,116.25
	$82.18	$4,109.00
	$79.06	$7,906.00

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	RF Cable Assemblies
RoHS:
Connector A Series:	2.92 mm
Connector A Gender:	Plug (Male)
Connector A Body Style:	Straight
Connector B Series:	SMPM
Connector B Gender:	Jack (Female)
Connector B Body Style:	Straight
Cable Length:	152 mm (5.984 in)
Impedance:	50 Ohms
Maximum Frequency:	40 GHz
Cable Type:	0.047 Flexible Coax
Packaging:	Bulk
Brand:	Samtec
Connector A Polarity:	Normal
Connector B Polarity:	Normal
Contact Material:	Copper
Contact Plating:	Gold
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	TW
Frequency Range:	0 Hz to 40 GHz
Minimum Frequency:	0 Hz
Polarity:	Normal
Product Type:	RF Cable Assemblies
Series:	RF047-A
Factory Pack Quantity:	1
Subcategory:	Cable Assemblies

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

RF047-A-92SP-M0SJ-0152 Datasheet (PDF)

Images


Specification Sheets

Technical Resources

Test Report (PDF)

CNHTS:: 8544200000
CAHTS:: 8544200000
USHTS:: 8544200000
JPHTS:: 854420000
KRHTS:: 8544200000
TARIC:: 8544200090
BRHTS:: 85442000
ECCN:: EAR99

18GHz to 110GHz RF Interconnect Solutions

Samtec offers complete RF interconnect solutions supporting traditional sub-6 GHz frequencies to 110GHz microwave/millimeter wave frequencies (sub-Terahertz spectrum). Samtec's Precision RF products are those supporting frequencies between 18GHz to 110GHz with precise, repeatable electrical and mechanical results and low VSWR. Interface types include 1mm, 1.35mm, 1.85mm, 2.40mm, 2.92mm, 3.50mm, SSMA, SMA, SMP, SMPM, ganged SMPM, N-Type, and TNCA. These devices are available in end-to-end microwave cable assemblies, phase and amplitude stable high-performance microwave cable assemblies, board connectors, cable connectors, and in-series and between-series adapter options.

RF047-A Millimeter Wave Cable Assemblies

Samtec RF047-A Millimeter Wave Cable Assemblies offer a 50Ω impedance and are manufactured with lead-free processing. These 0.047" low-loss flexible cable assemblies feature a 5mm minimum bend radius and 95pF/meter capacitance. Other key features include 70% propagation velocity and 2.26kg minimum connector retention. The RF047-A RF cable assemblies are 29AWG and operate within the -65ºC to 125ºC operating temperature range.
