TLE-140-01-G-DV-A

Images are for reference only
See Product Specifications

Mouser No:

200-TLE14001GDVA

Mfr. No:

TLE-140-01-G-DV-A

Mfr.:

Samtec

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Delivery Restriction:

Mouser does not presently sell this product in your region.

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Headers & Wire Housings
Delivery Restriction:	Mouser does not presently sell this product in your region.
RoHS:
Product:	Headers
Type:	Socket
Number of Positions:	80 Position
Pitch:	2 mm (0.079 in)
Number of Rows:	2 Row
Row Spacing:	2 mm (0.079 in)
Mounting Style:	SMD/SMT
Termination Style:	Solder
Mounting Angle:	Straight
Contact Gender:	Socket (Female)
Contact Plating:	Gold
Series:	TLE
Tradename:	Tiger Beam
Application:	Board-to-Board, Cable
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Packaging:	Tube
Brand:	Samtec
Contact Material:	Phosphor Bronze
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	VN
Current Rating:	3.2 A
Housing Colour:	Black
Housing Material:	Liquid Crystal Polymer (LCP)
Product Type:	Headers & Wire Housings
Factory Pack Quantity:	7
Subcategory:	Headers & Wire Housings
Unit Weight:	1.760 g
